ParFX Ultra

Product Details

Engineered to deliver a light output of up to 4585 μmol/s* and a system efficacy of 3.9 μmol/J*, the ParFX^TM Ultra delivers ultra-high performance in both full LED and/or hybrid applications.

An integrated driver, standard horticultural power connectors, and intuitive mounting allow for easy installation in both new or retrofit applications.

*R95B5 spectral recipe, 3-Channel Ultra Max model ^†R95B5 spectrum, Ultra Plus model

The ParFX^TM Ultra’s lens is optically engineered to deliver a wide or ultra-wide batwing distribution for exceptional uniformity. This ideal combination of wide light distribution and exceptionally high light output enables wider spacing, so growers can achieve desired light levels evenly across the surface of the crop with fewer luminaires.

The ParFX^TM Ultra is thermally and mechanically engineered to dissipate heat through conduction and convection paths—minimizing LED junction temperature and maximizing light output, lifetime, and reliability.

HOW IT WORKS

Convection currents draw cool air into the slots along either end of the luminaire.
The air then passes through the integrated fins that span the length of the luminaire, drawing heat away from the LEDs and electronics compartment.
These integrated aluminum fins also allow for additional conductive heat dissipation for optimal passive thermal management.

Technical Specifications^† – SINGLE CHANNEL Models
Rated Main Voltage	277-480V
Amperage (max)	277V		347V		400V		480V
Ultra	2.70		2.16		1.88		1.56
Ultra Plus	3.75		3.00		2.60		2.17
Power	R95:B5	R90:W5:B5	R80:W5:B7:FR8	R37:W37:B18:FR8	R57:W30:B12:FR1	R78:W9:B5:FR8	R85:W5:B5:FR5	R40:W40:B18:FR2
Ultra	750W	750W	750W	750W	750W	750W	750W	N/A
Ultra Plus	1040W	1040W	1040W	1040W	1040W	1040W	1040W	1040W
Light Source	LED
PF (350-800nm)	R95:B5	R90:W5:B5	R80:W5:B7:FR8	R37:W37:B18:FR8	R57:W30:B12:FR1	R78:W9:B5:FR8	R85:W5:B5:FR5	R40:W40:B18:FR2
Ultra	2827 μmol/s	2774 μmol/s	2849 μmol/s	2215 μmol/s	2189 μmol/s	2819 μmol/s	2929 μmol/s	N/A
Ultra Plus	4019 μmol/s	3813 μmol/s	3945 μmol/s	2990 μmol/s	3140 μmol/s	3869 μmol/s	3817 μmol/s	2765 μmol/s
PE (350-800nm)	R95:B5	R90:W5:B5	R80:W5:B7:FR8	R37:W37:B18:FR8	R57:W30:B12:FR1	R78:W9:B5:FR8	R85:W5:B5:FR5	R40:W40:B18:FR2
Ultra	3.7 μmol/J	3.7 μmol/J	3.8 μmol/J	2.9 μmol/J	2.9 μmol/J	3.8 μmol/J	3.6 μmol/J	N/A
Ultra Plus	3.9 μmol/J	3.7 μmol/J	3.8 μmol/J	2.9 μmol/J	3.0 μmol/J	3.8 μmol/J	3.7 μmol/J	2.72 μmol/J
Power Factor	> 0.97
Input Frequency	50/60Hz
Environment	35°C Max Ambient Operating Temperature; Suitable for Wet Locations
Dimming	0-10V (source*) / Digital^‡
Lifetime (L90)	L90B5 at 50,000 hrs**

Technical Specifications^† – TWO CHANNEL Models
Rated Main Voltage	277-400V
Amperage	277V		347V		400V
	CHANNEL 1	CHANNEL 2	CHANNEL 1	CHANNEL 2	CHANNEL 1	CHANNEL 2
Ultra	2.7	0.3	2.2	0.2	1.9	0.2
Ultra Plus	3.8	0.3	3.0	0.3	2.6	0.2
Ultra Max	4.3	0.4	3.4	0.3	3.0	0.3
Power	CHANNEL 1			CHANNEL 2
Ultra	750W			85W
Ultra Plus	1040W			95W
Ultra Max	1170W			115W
Light Source	LED
Spectrum	CHANNEL 1			CHANNEL 2
	R90:W5:B5			FR
Photon Flux (350-800nm)	Mode 1 (CH1-ON, CH2-OFF)		Mode 2 (CH1-OFF, CH2-ON)		Mode 3 (CH1-ON, CH2-ON)
Ultra	2700 μmol/s		281 μmol/s		2675 μmol/s
Ultra Plus	3744 μmol/s		314 μmol/s		3716 μmol/s
Ultra Max	4308 μmol/s		379 μmol/s		4274 μmol/s
Photon Efficacy (350-800nm)	Mode 1 (CH1-ON, CH2-OFF)		Mode 2 (CH1-OFF, CH2-ON)		Mode 3 (CH1-ON, CH2-ON)
	3.6 μmol/J		3.3 μmol/J		3.5 μmol/J
Power Factor	> 0.97
Input Frequency	50/60Hz
Environment	35°C Max Ambient Operating Temperature; Suitable for Wet Locations
Dimming	Digital Dim to Off^‡
Lifetime	L90B5 at 50,000 hrs**

Technical Specifications^† – Three CHANNEL Ultra max Model
Rated Main Voltage	277-400V
Amperage	277V	347V	400V
CHANNEL 1	4.3	3.5	3.0
CHANNEL 2	0.5	0.4	0.3
CHANNEL 3	0.7	0.6	0.5
Power CHANNEL 1	1200W
CHANNEL 2	130W
CHANNEL 3	190W
Light Source	LED
Dynamic Spectrum CHANNEL 1	95% Red 5% Blue (4585 μmol/s @ 100%)
CHANNEL 2	Far-Red (365 μmol/s @ 100%)
CHANNEL 3	White (400 μmol/s @ 100%)
Photon Flux (350-800nm)	Sample Recipe 1: R95:B5	Sample Recipe 2: R89:W5:B6	Sample Recipe 3: R81:W5:B6:FR8
Photon Flux (350-800nm)	4585 μmol/s	4345 μmol/s	4270 μmol/s
Photon Efficacy (350-800nm)	Sample Recipe 1: R95:B5	Sample Recipe 2: R89:W5:B6	Sample Recipe 3: R81:W5:B6:FR8
Photon Efficacy (350-800nm)	3.82 μmol/J	3.62 μmol/J	3.56 μmol/J
Power Factor	>0.97
Input Frequency	50/60Hz
Environment	35°C Max Ambient Operating Temperature; Suitable for Wet Locations
Dimming	Digital Dim to Off^‡
Lifetime	L90B5 at 50,000 hrs**

Technical Specifications^† – FOUR CHANNEL Ultra max Model
Rated Main Voltage	277-400V
Amperage	277V	347V	400V
CHANNEL 1	4.3	.3.5	3.0
CHANNEL 2	0.5	0.4	0.4
CHANNEL 3	0.8	0.6	0.6
CHANNEL 4	0.4	0.3	0.3
Power CHANNEL 1	1200W
CHANNEL 2	140W
CHANNEL 3	220W
CHANNEL 4	100W
Light Source	LED
Dynamic Spectrum CHANNEL 1	Red (4620 μmol/s @ 100%)
CHANNEL 2	Far-Red (390 μmol/s @ 100%)
CHANNEL 3	White (480 μmol/s @ 100%)
CHANNEL 4	Blue (235 μmol/s @ 100%)
Photon Flux (350-800nm)	Sample Recipe 1: R95:B5	Sample Recipe 2: R90:W5:B5	Sample Recipe 3: R80:W7:B5:FR8	Sample Recipe 4: R76:W6:B8:FR10
	4530 μmol/s	4360 μmol/s	4250 μmol/s	4130 μmol/s
Photon Efficacy (350-800nm)	Sample Recipe 1: R95:B5	Sample Recipe 2: R90:W5:B5	Sample Recipe 3: R80:W7:B5:FR8	Sample Recipe 4: R76:W6:B8:FR10
	3.78 μmol/J	3.63 μmol/J	3.54 μmol/J	3.44 μmol/J
Power Factor	>0.97
Input Frequency	50/60Hz
Environment	35°C Max Ambient Operating Temperature; Suitable for Wet Locations
Dimming	Digital Dim to Off^‡
Lifetime	L90B5 at 50,000 hrs**

†Accurate to ± 10% *The ParFX Ultra is designed as a 0-10V sourcing supply and is compatible with most major environmental control systems that use 0-10V sinking protocols—including Hoogendoorn, Priva, Argus Control Systems, and Wadsworth Control Systems. ^‡Digital dimming is based on RS485 standard. Available for MeshIQ-enabled models only. **Scientifically extrapolated calculation for Par Maintenance of light is L90B5 at 50,000hrs (this means that the expected lifespan of LEDs is defined as ≤5% of luminaires can depreciate below the expected 90% PAR maintenance within a specified number of hours.

DIMENSIONS
	Ultra	Ultra Plus	Ultra Max
x = length	24.41 in (620 mm)	22.91 in (582 mm)	28.43 in (722 mm)
y = width	11.65 in (296 mm)	13.98 in (355 mm)	15.16 in (385 mm)
z = height	3.58 in (91 mm)	4.13 in (105 mm)	4.57 in (116 mm)
weight	22.1 lb. (10 kg)	28.7 lb. (13 kg)	37.5 lb. (17.0 kg)

Environment

The product is meant for use in climate-controlled rooms. The product may be used in damp environments. The product may not be used in wet environments or outdoors. The LEDs function optimally when the ambient temperature is between 0 ~ 35 °Celsius.

Certifications

Warranty

Limited warranty for a period of 5 years from the date of invoice. Refer to the relevant luminaire specification data sheet for expected LED lifetime data.

If you are experiencing problems with your luminaire, please contact our customer service team to arrange for additional technical support or service repairs as required.

SpectrAL Options

Designed to deliver optimum color efficiencies, the ParFX^TM Ultra is available in multiple standard spectral recipes. Custom spectral recipes can be accommodated for project-level orders.

LIGHT DISTRIBUTION

The ParFX^TM Ultra offers medium-wide (standard) or ultra-wide optical lens options, each delivering optimized batwing distribution for exceptional uniformity—depending on your application.

LIGHT OUTPUT

The ParFX^TM Ultra is available in high light output (Ultra), ultra-high output (Ultra Plus), or super-high (Ultra Max) models—depending on the light levels required for your application.
